Free Standing Rig - 2 Cell

Two Cells. Four Athletes. No Wall Needed.

The Phoenix Free Standing 2 Cell Rig is the most popular entry point for commercial gym operators who need functional training capacity without a structural wall. Two 1080mm cells joined by an 1800mm connector, eight uprights, four athletes training at once, two per side.

Each cell fits a full-size 7ft barbell with correct spacing on both sides. That's four barbell stations from a single self-supporting frame. The rig stands on its own base plate system, no wall anchoring required, although wall anchoring can be added for additional rigidity in high-volume facilities.

Choose standard 1080mm depth for the most common commercial configuration, or wide boy 1800mm depth where space allows or the application demands it. Both work on either side of the rig.

System Specs

• Uprights: 75 x 75mm SHS, 4mm wall (Premium) or 3mm wall (Standard)
• Hole diameter: 25mm | Hole spacing: 25mm centres
• Heights: 2500mm / 2750mm / 3000mm / 3500mm
• Standard depth: 1080mm | Wide boy depth: 1800mm
• Compatible with all Phoenix and Valkyrie attachments (25mm/25mm spec)
• Bolt-together construction, modular, add cells later
• Finish: Powder coat black (custom RAL available)

What's Included

Each system is quoted as a complete configured package including uprights, base plates, crossbeams, chin bars, J-hooks, and safety spotter arms. Additional accessories quoted separately. Call Andy to spec your system and get a line-item quote within 24 hours.

Phone: 0422 046 895
